Winters Instruments PCT327 Pct Contractor Pressure Gauge/ Pct-Lf Lead Free Contractor Gauge – One-stop shop for professional tools and equipment.

Description

Product Description

Winters Instruments – PCT327

Features

• Economical 4.5” (115mm) stainless steel case gauge
• Brass or lead free brass wetted parts
• ±1% accuracy
• Zero adjustment screw
• 1/4” NPT
• Restricted orifice
• ASME B40.100 compliant
• CRN registered
• Lead free version NSF-61-372 certified
• 5 year warranty

Applications

• Most commercial air, water and steam services (with syphon)
• Lead free version for potable water systems

Additional Information

Dial4.5” (115mm) white aluminum dial with black and red markings

Case304 SS

LensAcrylic

Ring304 SS

SocketPCT: Brass, PCT-LF: Lead free brass, NSF-61-372 certified

Connection1/4” NPT standard

Bourdon TubePhosphor bronze

MovementPCT: Brass, PCT-LF: Lead free brass, NSF-61-372 certified

PointerAluminum, anodized black, recalibrator screw

WeldingSilver solder

Over-Pressure Limit25% for pressures up to 1,450 psi (9,998 kPa), 15% for pressures over 1,500 psi (10,342 kPa)

Working PressureMaximum 75% of full scale value

Ambient/Process Temperature-40°F to 200°F (-40°C to 93°C)

Accuracy±1% ANSI/ASME Grade 1A

Enclosure RatingIP52

WarningThis product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
