Description

Product Description

White Rodgers – 30-46-005S1 Mercury Flame Sensor, Stud Mount, 48 Element

Features:

• Sensor combines a rugged Snap-Action switch and powerful mercury actuated thermal element
• May be used with natural, manufactured or mixed gases and with LP gases where means are provided for obtaining automatic pilot gas shut-off
• Switch may be conveniently mounted in any position
• Cover is easily removed, making switch terminals readily accessible
• No button to depress ? Sensor is recycling type which requires relighting or possible restoration of proper gas pressure to return to operation

Additional Information

Length48 Element

Voltage125 VA at 120 Vac, 240 Vac, 90 VA at 30 Vac

TimingsContacts close approximately 60 seconds after pilot is ignited; open approximately 40 seconds after flame is extinguished
